OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial

SKU: T-55265GD057J-LW-AKN
Model Number: T-55265GD057J-LW-AKN
Diagonal Size: 5.7 inches
Resolution: 320 × 240 QVGA
Display Technology: a-Si TFT-LCD, Transflective
0.0 (0 Reviews)
0 Sold
$126.00 $125.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
1/1
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
  • Description
OPTREX 5.7 inch 320×240 LCD Panel Display T-55265GD057J-LW-AKN For Industrial
Parameter Specification
Model Number T-55265GD057J-LW-AKN
Diagonal Size 5.7 inches
Resolution 320 × 240 QVGA
Display Technology a-Si TFT-LCD, Transflective
Display Mode Normally White
Color Depth 262K Colors (18-bit RGB)
Brightness 450 cd/m² Typical
Contrast Ratio 500:1 Typical
Viewing Angle Full Wide View Industrial Grade
Interface 8-bit MCU Parallel / RGB Interface
Supply Voltage 3.3V DC
Backlight Integrated White LED Backlight
Operating Temperature -20 ℃ ~ +70 ℃
Storage Temperature -30 ℃ ~ +80 ℃
Outline Dimension Standard 5.7 inch industrial module size
Touch Panel Without Touch (Optional Resistive Touch)
RoHS Compliant

Typical Applications

  • Industrial automation HMI and machine control panels
  • Portable handheld terminals and measuring instruments
  • Medical diagnostic and monitoring equipment
  • Outdoor sunlight-readable industrial display devices
  • Vehicle-mounted and marine industrial display terminals
  • Smart home control panels and IoT display terminals
  • Instrumentation, testing and analysis equipment
