Condition: New
Warranty: 90 Days
Lead Time: 1-3 Working days
Shipping: DHL ,FedEx, EMS , SF express or by air.
| Parameter | Specification |
|---|---|
| Model Number | TCG057QVLBA-G00 |
| Manufacturer | Kyocera Display Solutions |
| Display Type | TFT Active Matrix LCD |
| Screen Size | 5.7 inches (Diagonal) |
| Resolution | 320 (RGB) × 240 pixels (QVGA) |
| Aspect Ratio | 4:3 |
| Pixel Pitch | 0.360 × 0.360 mm |
| Active Area | 115.2 × 86.4 mm (Approx.) |
| Outline Dimensions | 144.0 × 104.0 × 12.7 mm (Approx.) |
| Brightness | 500 cd/m² (Typical), suitable for outdoor/semi-outdoor use |
| Contrast Ratio | 350:1 (Typical) |
| Color Depth | 262K colors (6-bit) or 16.7M colors (8-bit, depending on driver) |
| Viewing Angle | 12 o'clock direction (Top view optimized) or Wide View (IPS variant if applicable) |
| Backlight | LED Backlight |
| Interface | TTL / LVDS (Check specific datasheet for pinout) |
| Operating Temp. | -20°C to +70°C (Standard Industrial Range) |
| Storage Temp. | -30°C to +80°C |
| Touch Panel | Often available as an integrated option (Resistive/Capacitive) |
| Mounting | Rear mounting holes provided |
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
