KYOCERA NEW 5.7 inch LCD Display Panel TCG057QVLGA-G00 for Industrial
| Parameter |
Value |
| Model |
TCG057QVLGA-G00 |
| Brand |
KYOCERA |
| Display Type |
a-Si TFT-LCD, Transmissive, TN Mode |
| Screen Size |
5.7 inches |
| Resolution |
320(RGB) × 240 (QVGA) |
| Pixel Density |
70 PPI |
| Color Support |
262K colors (6-bit) |
| Brightness |
500 cd/m² (Typical, High Brightness) |
| Contrast Ratio |
500:1 (Typical) |
| Viewing Angle |
80/80/80/80 (Typ., CR≥5) |
| Operating Temperature |
-20°C to +70°C |
| Storage Temperature |
-30°C to +80°C |
| Backlight |
WLED (White LED), Side-entry, 70,000 hours (Typ.) |
| Supply Voltage |
3.3V (Logic), 9.0V~10.6V (Backlight) |
| Interface |
33-pin Parallel RGB (1 channel, 6-bit), Terminal |
| Dimensions |
134.5(H) × 103.4(V) × 9.35(D) mm (Outline) |
| Active Area |
115.2(H) × 86.4(V) mm |
The KYOCERA TCG057QVLGA-G00 is designed for industrial applications that require reliable performance and visibility in bright environments (Sunlight Readable). Its 500 nits brightness and robust design make it suitable for:
- Industrial Automation: Human-Machine Interface (HMI) panels and control units located on factory floors with high ambient lighting.
- Outdoor Kiosks & ATMs: Self-service terminals and Point-of-Sale (POS) systems where screen readability in daylight is essential.
- Medical Equipment: Patient monitoring systems and diagnostic devices requiring stable, clear displays.
- Transportation & Marine: Control displays for vehicles, marine navigation systems, and dashboard instruments.
- Test & Measurement: Portable field equipment used by engineers in various lighting conditions.
- CNC Machinery: Operator panels for (CNC machines) in workshops.
KYOCERA
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
- Q: May I ask what kind of packaging you use?
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
