| Parameter | Specification | Details |
|---|---|---|
| Model Number | TCG057QVLHA-G00 | - |
| Manufacturer | Kyocera (Japan) | Formerly Optrex |
| Screen Size | 5.7 inches | Diagonal measurement |
| Display Technology | a-Si TFT-LCD | Active Matrix, Transmissive |
| Resolution | 320 (RGB) × 240 | QVGA Format |
| Aspect Ratio | 4:3 | Standard industrial ratio |
| Pixel Pitch | 0.360 × 0.360 mm | Large pixels for high visibility |
| Display Colors | 262K / 16.2M | 6-bit or 8-bit per color (TTL) |
| Interface Type | TTL / CMOS | Digital RGB parallel interface |
| Connector | 30-pin or 34-pin FPC/Connector | Specific to Kyocera pinout |
| Brightness | 800 cd/m² (Typical) | Ultra-High Brightness (Sunlight Readable) |
| Contrast Ratio | 400:1 ~ 500:1 (Typical) | High contrast maintained at high brightness |
| Viewing Angle | 80/80/80/80 (Typ.) | CR ≥ 10 (All directions) |
| Backlight Type | WLED (White LED) | High power LED array |
| Backlight Life | ~70,000 - 100,000 hours | Until 50% brightness decay |
| Active Area | 115.20 (W) × 86.40 (H) mm | Viewable image size |
| Module Dimensions | Approx. 132.0 (W) × 105.0 (H) × 11.5 (D) mm | Includes backlight unit |
| Supply Voltage | 3.3V (Logic) / 12V-24V (Backlight Driver) | Check specific driver requirements |
| Operating Temp. | -30°C to +80°C | Extended Industrial Temperature Range |
| Storage Temp. | -40°C to +85°C | - |
| Weight | Approx. 200g - 250g | Robust metal frame |
| Surface Treatment | Anti-Glare (AG) / Hard Coat | Essential for outdoor readability |
