KYOCERA NEW 5.7 inch LCD Display Panel TCG057QVLPMANN-GN50 for Industrial
| Parameter |
Value |
| Model |
TCG057QVLPMANN-GN50 |
| Brand |
KYOCERA |
| Display Type |
a-Si TFT-LCD (Transmissive Color TFT) |
| Screen Size |
5.7 inches |
| Resolution |
320(RGB) × 240 (QVGA) |
| Color Support |
262K colors (6-bit) |
| Brightness |
500 cd/m² (Typical, High Brightness) |
| Contrast Ratio |
500:1 (Typical) |
| Display Mode |
TN, Normally White, Transmissive |
| Surface Treatment |
Glare (Haze 0%) |
| Operating Temperature |
-30°C to +80°C (Wide Temperature) |
| Storage Temperature |
-30°C to +80°C |
| Backlight |
WLED, 50,000 hours (Typical lifetime) |
| Supply Voltage |
3.3V (Typical) |
| Interface |
33-pin Parallel RGB (1 channel, 6-bit), Terminal |
| Dimensions |
127.2(H) × 100.4(V) × 6.0(D) mm (Outline) |
The KYOCERA TCG057QVLPMANN-GN50 is engineered for environments requiring high visibility and stability under extreme temperatures. Its high brightness (500 nits) and wide temperature range (-30°C to +80°C) make it suitable for the following specific applications:
- Outdoor Industrial Equipment: Ruggedized handheld terminals and field service devices where sunlight readability is critical.
- Transportation & Automotive: In-vehicle displays for construction machinery, agricultural vehicles, and logistics fleets that operate in varying weather conditions.
- Medical Devices: Portable medical instruments and diagnostic equipment requiring stable display performance and high reliability.
- Factory Automation: Human-Machine Interface (HMI) panels and PLC control units installed in non-climate-controlled factory floors.
- Test & Measurement: Portable testing equipment used in outdoor or semi-outdoor environments (e.g., construction sites).
- Legacy System Upgrades: Replacement displays for older industrial systems utilizing standard Parallel RGB interfaces.
