TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera

SKU: TCG084SVLAACFA-AA20
Model: TCG084SVLAACFA-AA20
Diagonal Size: 8.4 inch
Display Type: a-Si TFT-LCD, Transmissive, Normally White
Native Resolution: 800 × 600 (SVGA, 4:3)
0.0 (0 Reviews)
0 Sold
$230.00 $220.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
1/1
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
  • Description
TCG084SVLAACFA-AA20 8.4 inch 800×600 LCD Panel Display For Kyocera
Parameter Specification
Brand Kyocera
Model TCG084SVLAACFA-AA20
Diagonal Size 8.4 inch
Display Type a-Si TFT-LCD, Transmissive, Normally White
Native Resolution 800 × 600 (SVGA, 4:3)
Active Display Area 170.4 mm (W) × 127.8 mm (H)
Outline Dimension 199.5(W)×147.4(H)×11.55(D) mm
Pixel Pitch 0.213 mm × 0.213 mm
Brightness 320 cd/m² (Typ.)
Contrast Ratio 500:1 (Typ.)
Viewing Angle 85°/85°/85°/85° (L/R/U/D, CR≥10)
Color Depth 16.7M colors, 8-bit
Backlight WLED, integrated driver, 100,000 hours lifetime
Interface Single channel LVDS, 6/8-bit
Touch Panel 4-wire resistive touch screen integrated
Surface Treatment Anti-glare, 2H hard coating
Operating Temperature -20℃ ~ +70℃
Storage Temperature -30℃ ~ +80℃
Supply Voltage 3.3V / 5.0V standard industrial input
Net Weight Approx. 400g
Compliance RoHS

Typical Applications (English)

  • Industrial automation HMI, PLC control panels and CNC machine tool operation interfaces
  • Medical diagnostic equipment, patient monitoring devices and laboratory analytical instruments
  • Industrial embedded computers, industrial panel PCs and factory automation terminals
  • Transportation onboard displays, engineering machinery and agricultural equipment dashboards
  • Self-service kiosks, vending machines, industrial POS and intelligent cabinet control screens
  • Smart factory equipment, environmental monitoring terminals and harsh indoor industrial display systems
