Kyocera TCG104SVLQJPNN-AN40 10.4 inch 800×600 a-Si TFT-LCD, LCM LCD Panel for Industrial

Name: Kyocera TCG104SVLQJPNN-AN40 10.4 inch 800×600 a-Si TFT-LCD, LCM LCD Panel for Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: TCG104SVLQJPNN-AN40
Price: 210 USD
Availability: InStock

SKU: TCG104SVLQJPNN-AN40

Model P/N： TCG104SVLQJPNN-AN40
Diagonal Size： 10.4"
Panel Type： a-Si TFT-LCD, LCM
Resolution： 800(RGB)×600, SVGA 96PPI
Pixel Format： RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$212.00~~ $210.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Kyocera TCG104SVLQJPNN-AN40 10.4 inch 800×600 a-Si TFT-LCD, LCM LCD Panel for Industrial

Parameter	Specification
Model Number	TCG104SVLQJPNN-AN40
Manufacturer	Kyocera (Japan)
Panel Size	10.4 inch (Diagonal)
Resolution	800 (RGB) × 600 [SVGA]
Pixel Pitch	0.264 mm (H) × 0.264 mm (V)
Display Type	a-Si TFT-LCD, Transmissive, Normally White
Brightness	1300 cd/m² (Typ.) - Very High Brightness for Sunlight Readability
Contrast Ratio	800:1 (Typ.)
Viewing Angle	85/85/85/85 (Left/Right/Up/Down) (CR≥10)
Color Depth	16.7M Colors (8-bit per color)
Interface	LVDS (Low-Voltage Differential Signaling), 1 channel, 24-bit
Connector	30-pin LVDS (Specific pinout for AN40 revision)
Backlight Type	WLED (White LED)
Backlight Life	≥ 50,000 hours (to 50% brightness)
Operating Temperature	-30°C to +80°C (Wide Temperature Range)
Storage Temperature	-40°C to +90°C
Active Area	211.2 mm (H) × 158.4 mm (V)

Specific Applications

The TCG104SVLQJPNN-AN40 is a premium 10.4-inch SVGA display engineered specifically for direct sunlight readability and harsh environmental conditions. Its 1300 nits brightness and wide temperature range make it ideal for:

Outdoor Industrial Control & HMI:
- Perfect for sunlight-readable control panels on construction machinery (excavators, cranes), agricultural tractors, and mining vehicles where operators need clear visibility under direct sun.
- Used in outdoor self-service kiosks (ticketing, parking, fuel pumps) located in unshaded areas.
Transportation & Marine:
- Applied in railway cab displays, marine bridge navigation systems, and aviation ground support equipment. The wide temperature range (-30°C to +80°C) ensures reliable operation in unheated cabins or exposed deck environments.
Military & Defense:
- Integrated into ruggedized handheld devices, vehicle-mounted command centers, and field communication units requiring high brightness for daytime operations and resistance to extreme thermal shock.
Oil, Gas & Energy:
- Deployed in drilling rig monitors and remote pipeline control stations exposed to intense solar radiation and extreme ambient temperature swings.
Emergency & Public Safety Vehicles:
- Used in mobile command centers and emergency response vehicles (fire trucks, ambulances) where reliable, high-contrast display performance is critical for situational awareness in all weather and lighting conditions.
