10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel

SKU: TCG104VG2AL-H00
Model Number: TCG104VG2AL-H00
Brand: KYOCERA
Diagonal Size: 10.4 Inch
Native Resolution: 640(RGB) × 480 VGA, 4:3 Aspect Ratio
Display Mode: a-Si TFT-LCD
0.0 (0 Reviews)
0 Sold
$195.00 $190.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
1/1
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • 10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
  • Description
10.4 Inch Kyocera TCG104VG2AL-H00 640×480 Industrial TFT LCD Screen Display Panel
Item Specification Parameter
Model Number TCG104VG2AL-H00
Brand KYOCERA
Diagonal Size 10.4 Inch
Native Resolution 640(RGB) × 480 VGA, 4:3 Aspect Ratio
Display Mode a-Si TFT-LCD
Backlight Edge WLED, Built-in Constant Current Circuit, Lifespan ≥70,000 Hours
Typical Brightness 400 cd/m²
Contrast Ratio 500:1
Viewing Angle L/R/U/D (CR≥10) 70° / 70° / -70° / 60°
Signal Interface CMOS Parallel RGB 6-bit Digital Interface
Refresh Rate 60Hz
Active Display Area 211.2 (W) × 158.4 (H) mm
Overall Outline Dimension 240.7 (W) × 180.2 (H) × 9.0 (T) mm
Surface Treatment Standard Anti-Glare Hard Coating, Anti-scratch
Touch Function Without touch digitizer (Resistive touch glass optional)
Operating Temperature -20℃ ~ +70℃
Storage Temperature -30℃ ~ +80℃
Logic Supply Voltage 3.3V Industrial Standard
Backlight Input Voltage 12V
Net Weight Approx 445g
Quality Grade Original New Grade A, Full Aging & Function Tested Before Shipment

Applications

  1. Industrial HMI & Factory Automation Equipment
    CNC machine operation panels, PLC control terminals, injection molding machine displays, robotic control consoles, packaging machinery screens, factory monitoring HMI, assembly line touch control terminals.
  2. Medical Diagnostic & Monitoring Devices
    Bedside patient monitors, portable ECG analyzers, infusion pump control screens, clinical testing instruments, veterinary diagnostic equipment, medical auxiliary imaging display modules.
  3. Laboratory & Precision Test Measuring Instruments
    Power quality analyzers, environmental gas detection testers, optical measuring equipment, pipeline inspection devices, industrial data recorders, oscilloscope auxiliary display panels.
  4. Construction & Agricultural Machinery On-board Displays
    Forklift monitoring dashboards, tractor control screens, excavator parameter displays, engineering vehicle operation terminals, agricultural spraying machine control panels.
  5. Commercial Self-service & Special Industrial Equipment
    Industrial vending machine control modules, mining safety monitoring screens, marine small instrument displays, factory access control terminals, battery-powered portable industrial detectors.
