Kyocera TCG104VGLAAANN-AN20 10.4 inch 640×480 a-Si TFT-LCD, LCM LCD Panel for Industrial

Name: Kyocera TCG104VGLAAANN-AN20 10.4 inch 640×480 a-Si TFT-LCD, LCM LCD Panel for Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: TCG104VGLAAANN-AN20
Price: 290 USD
Availability: InStock

SKU: TCG104VGLAAANN-AN20

Model P/N : TCG104VGLAAANN-AN20
Diagonal Size : 10.4"
Panel Type : a-Si TFT-LCD, LCM
Resolution : 640(RGB)×480, VGA 76PPI
Pixel Format : RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$320.00~~ $290.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Kyocera TCG104VGLAAANN-AN20 10.4 inch 640×480 a-Si TFT-LCD, LCM LCD Panel for Industrial

Parameter	Specification
Model Number	TCG104VGLAAANN-AN20
Manufacturer	Kyocera
Panel Size	10.4 inch
Resolution	640 (RGB) × 480
Pixel Pitch	0.33 mm (H) × 0.33 mm (V)
Display Type	a-Si TFT-LCD, Transmissive, Normally White
Brightness	800 ~ 1000 cd/m² (Typ.) - High Brightness
Contrast Ratio	700:1 ~ 800:1 (Typ.)
Viewing Angle	85/85/85/85 (Left/Right/Up/Down) (CR≥10)
Color Depth	16.7M Colors (8-bit per color) or 262K (6-bit + FRC)
Interface	LVDS (Low-Voltage Differential Signaling), 1 channel, 24-bit
Connector	30-pin or 20-pin LVDS (Specific to AN20 revision)
Backlight Type	WLED (White LED)
Backlight Life	≥ 50,000 hours (to 50% brightness)
Operating Temperature	-30°C to +80°C
Storage Temperature	-40°C to +90°C

Specific Applications

The TCG104VGLAAANN-AN20 is a versatile 10.4-inch VGA display designed for environments requiring reliable visibility, wide temperature tolerance, and long-term availability:

Industrial Automation & HMI:
- Widely used in Human-Machine Interfaces (HMI) for factory control panels, PLC operator terminals, and robotic system monitors where a clear VGA resolution is standard for process visualization.
Medical Equipment:
- Integrated into patient monitoring systems, mobile medical carts, and diagnostic devices. The LED backlight ensures stable brightness over thousands of hours of continuous operation required in hospitals.
Transportation Systems:
- Ideal for railway passenger information displays, onboard ticketing machines, and marine navigation instruments. The wide operating temperature (-30°C to +80°C) allows it to function in unheated vehicle cabins or exposed deck areas.
Test & Measurement Instruments:
- Used in portable field testers, power grid monitoring units, and environmental data loggers that need to operate reliably in varying weather conditions and outdoor lighting.
Legacy System Upgrades:
- Frequently selected as a direct replacement for older 10.4" CCFL displays in banking ATMs, gaming machines, and lottery terminals, offering improved energy efficiency, lower heat generation, and elimination of high-voltage inverters.
