Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen

SKU: TCG104VGLPAANN-AN20-ZG
Model No.: TCG104VGLPAANN-AN20-ZG
Diagonal Size: 10.4 inch
Native Resolution: 640 × 480 (VGA, RGB Stripe)
Display Type: a-Si TN TFT-LCD
0.0 (0 Reviews)
0 Sold
$274.00 $272.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
1/1
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
  • Description
Kyocera TCG104VGLPAANN-AN20-ZG 10.4 Inch VGA 640×480 Industrial TFT LCD Panel Display Screen
Parameter Item Specific Specification
Model No. TCG104VGLPAANN-AN20-ZG
Brand Kyocera Industrial Display
Diagonal Size 10.4 inch
Native Resolution 640 × 480 (VGA, RGB Stripe)
Display Type a-Si TN TFT-LCD, Transmissive Normally White
Active Area 211.2(W) × 158.4(V) mm
Overall Outline Size 240.7(W) × 180.2(H) × 9.0(D) mm
Typical Net Weight 470g
Brightness 400 cd/m² (Typical)
Contrast Ratio 500:1 (Typical)
Viewing Angle (CR≥10) Horizontal ±70°, Vertical -70° / +60°
View Direction 6 o’clock
Backlight WLED, Service Life 70,000 Hours, Built-in LED Driver & CCC Constant Current Circuit
Signal Interface Standard CMOS Interface
Power Supply Voltage 3.0V ~ 3.6V DC (Typ. 3.3V)
Color Depth 262K Display Colors
Surface Treatment Anti-Glare Hard Coating
Touch Function Without Touch Glass
Operating Temperature -20°C ~ +70°C
Storage Temperature -30°C ~ +80°C

Application Scenarios

  1. Industrial HMI Human Machine Interface, PLC Control Cabinet Operation Displays
  2. CNC Lathe, Milling Machine, Injection Molding & Packaging Automation Control Panels
  3. Portable Medical Monitoring Equipment, Diagnostic Analyzers, Bedside Medical Terminals
  4. Laboratory Test & Measuring Instruments, Industrial Inspection Detection Devices
  5. Construction Machinery, Forklift, Agricultural Vehicle On-board Control Terminals
  6. Intelligent Charging Piles, New Energy Equipment Monitoring Screens
  7. Printing, Textile, Welding Equipment Operating Display Modules
  8. Factory Automation Assembly Line Touch Display Terminals
  9. Small Marine Monitoring Equipment, Indoor Industrial Monitoring Terminals
