KYOCERA NEW 12.1 inch LCD Display Panel TCG121SVLABBNN-AN00 for Industrial
| Parameter |
Specification |
| Model Number |
TCG121SVLABBNN-AN00 |
| Brand |
Kyocera (Japan) |
| Panel Type |
a-Si TFT-LCD, LCM (Liquid Crystal Module) |
| Screen Size |
12.1 inches |
| Resolution |
800(RGB) × 600 (SVGA) |
| Brightness |
500 cd/m² (Typ.) |
| Contrast Ratio |
1000:1 (Typ.) |
| Display Mode |
TN, Normally White, Transmissive |
| Color Depth |
262K Colors (6-bit + FRC) |
| Response Time |
4/22 (Typ.) (Tr+Td) ms |
| Viewing Angles |
80/80/80/65 (Typ.) (CR≥10) |
| Backlight |
WLED (White LED) with LED Driver (70,000 hours life) |
| Interface |
30 pins RGB (1ch, 6-bit) |
| Operating Temp |
-20°C to +70°C |
| Outline Dimensions |
278.3(W) × 207.5(H) × 9.5(D) mm |
| Active Area |
246.0(W) × 184.5(H) mm |
| Surface Treatment |
Haze (Matte) |
This display module is designed for rugged industrial environments and is commonly used in the following applications:
- Industrial Control & Automation:
- CNC Machine Tools: Control panels for industrial machinery, including brands like FANUC, Siemens, and Mitsubishi.
- Factory Automation: Human Machine Interfaces (HMI) for manufacturing equipment.
- Medical Equipment:
- Displays for medical instruments and monitoring systems.
- Transportation & Marine:
- Vehicle Navigation: In-vehicle navigation systems.
- Marine Displays: Navigation screens for ships.
- Point of Sale (POS) & Kiosks:
- ATMs (Automated Teller Machines): Banking terminals.
- Self-Service Terminals: Information kiosks and payment terminals.
- Handheld & Portable Devices:
- Handheld PDA: Industrial data collectors and handheld terminals.
