KYOCERA NEW 12.1 inch LCD Display Panel TCG121SVLPAANN-AN51 for Industrial
| Parameter |
Specification |
| Model Number |
TCG121SVLPAANN-AN51 |
| Brand |
Kyocera (Japan) |
| Panel Type |
a-Si TFT-LCD, LCM (Liquid Crystal Module) |
| Screen Size |
12.1 inches |
| Resolution |
1024 × 768 (XGA) |
| Brightness |
500 cd/m² (Typ.) |
| Contrast Ratio |
750:1 (Typ.) |
| Display Mode |
Normally Black, Transmissive |
| Color Depth |
256K / 16.2M Colors (50% NTSC) |
| Backlight |
WLED (White LED) with LED Driver (50,000 hours life) |
| Interface |
20 pins LVDS (1ch, 6/8-bit) |
| Operating Temp |
-30°C to +80°C (Wide Temperature) |
| Outline Dimensions |
260.5(W) × 203.4(H) × 10.8(D) mm |
| Active Area |
239.6(W) × 179.7(H) mm |
| Surface Treatment |
Haze (Matte) |
This display module is designed for rugged industrial environments and is commonly used in the following applications:
- Industrial Control & Automation:
- CNC Machine Tools: Control panels for industrial machinery, including brands like FANUC, Siemens, and Mitsubishi.
- Factory Automation: Human Machine Interfaces (HMI) for manufacturing equipment.
- Medical Equipment:
- Displays for medical instruments and monitoring systems.
- Transportation & Marine:
- Vehicle Navigation: In-vehicle navigation systems.
- Marine Displays: Navigation screens for ships.
- Point of Sale (POS) & Kiosks:
- ATMs (Automated Teller Machines): Banking terminals.
- Self-Service Terminals: Information kiosks and payment terminals.
- Handheld & Portable Devices:
- Handheld PDA: Industrial data collectors and handheld terminals.
