KYOCERA NEW 12.1 inch LCD Display Panel TCG121SVLQKPGK-NA00 for Industrial
| Parameter |
Specification Details |
| Model Number |
TCG121SVLQKPGK-NA00 |
| Manufacturer |
Kyocera Display Solutions |
| Display Size |
12.1 inches (Diagonal) |
| Active Area (AA) |
245.76 mm (H) × 184.32 mm (V) |
| Resolution |
800 (RGB) × 600 pixels (SVGA) |
| Pixel Pitch |
0.3072 mm (H) × 0.3072 mm (V) |
| Pixel Arrangement |
RGB Vertical Stripe |
| Display Mode |
Transmissive, Normally White |
| Panel Technology |
a-Si TFT-LCD |
| Brightness |
500 cd/m² (Typical) – High Brightness for Indoor/Semi-Outdoor |
| Contrast Ratio |
1000:1 (Typical) |
| Viewing Angle |
80°/80°/80°/65° (Left/Right/Up/Down) @ CR≥10 |
| Color Depth |
262k Colors (6-bit) or 16.7M Colors (8-bit), depending on interface mode |
| Interface Type |
Parallel RGB (TTL) or LVDS
(Crucial: The "Q" series often implies Parallel RGB/TTL; verify pinout against datasheet) |
| Connector Type |
Specific Hirose or custom connector (Pin count varies by interface, typically 40-50 pins for TTL) |
| Backlight Type |
WLED (White LED) with integrated driver |
| Backlight Lifetime |
≥ 50,000 hours (to 50% brightness) |
| Operating Temperature |
-20°C to +70°C (Wide Temperature Range) |
| Storage Temperature |
-30°C to +80°C |
| Power Supply |
3.3V ±0.3V (Logic); Backlight voltage regulated by driver |
| RoHS Compliance |
Yes (Lead-free) |
| Touch Panel |
None (Module only; compatible with external touch overlays) |
| Mounting |
Metal bezel with standard industrial screw holes |
The TCG121SVLQKPGK-NA00 is widely used in sectors that demand ruggedness and long product lifecycles:
-
Legacy Industrial Equipment Upgrades:
- Ideal for replacing aging CCFL-backlit screens in older CNC machines, PLC control panels, and factory automation systems that originally utilized Parallel RGB (TTL) interfaces. Its form factor and electrical compatibility make it a perfect "drop-in" replacement.
-
Factory Automation & HMI:
- Serves as the Human-Machine Interface (HMI) for assembly lines, robotic controllers, and monitoring stations. The 500-nit brightness ensures clear visibility under bright factory lighting, and the wide temperature range handles unheated warehouses.
-
Medical Instrumentation:
- Used in patient monitoring systems, infusion pumps, and diagnostic devices where stable, flicker-free imaging and long-term availability are critical for regulatory compliance and device longevity.
-
Transportation & Railway (Onboard Systems):
- Deployed in train control consoles and passenger information displays. The ability to withstand vibration and temperature extremes (-20°C to +70°C) makes it suitable for rail environments.
-
Test & Measurement Devices:
- Integrated into oscilloscopes, power supplies, and environmental test chambers used in laboratories and field services.
-
Semiconductor Manufacturing:
- Used in equipment control panels within cleanrooms, where reliability and resistance to continuous operation are paramount.
