KYOCERA NEW 12.1 inch LCD Display Panel TCG121WXLRXVNN-ANX35 for Industrial
| Parameter |
Specification |
| Model Number |
TCG121WXLRVNN-ANX35 |
| Brand |
Kyocera (Japan) |
| Panel Type |
a-Si TFT-LCD, LCM (Liquid Crystal Module) |
| Screen Size |
12.1 inches |
| Resolution |
1280(RGB) × 800 (WXGA) |
| Brightness |
1500 cd/m² (Typ.) - High Brightness |
| Contrast Ratio |
750:1 (Typ.) |
| Display Mode |
AWV (All Way View), Normally Black, Transmissive |
| Pixel Density |
124 PPI |
| Color Depth |
16.7M Colors (50% NTSC) |
| Backlight |
WLED (White LED) with LED Driver |
| Interface |
20 pins LVDS |
| Operating Temp |
-30°C to +80°C (Wide Temperature) |
| Outline Dimensions |
283.0(W) × 185.1(H) × 11.0(D) mm |
| Active Area |
261.12(W) × 163.2(H) mm |
| Surface Treatment |
Haze (Matte) |
Due to its high brightness (1500 nits), wide temperature range (-30°C to 80°C), and industrial-grade durability, this display module is specifically designed for the following applications:
- Industrial Control & Automation:
- CNC Machine Tools: Control panels for brands like FANUC, Siemens, and Mitsubishi.
- Factory Automation: Human Machine Interfaces (HMI) and programmable logic controller (PLC) displays.
- Medical Equipment:
- Diagnostic imaging displays and patient monitoring systems requiring high reliability.
- Transportation & Marine:
- Vehicle Navigation: On-board computers and navigation systems for heavy machinery or specialized vehicles.
- Marine Displays: Navigation screens for ships (resistant to temperature fluctuations).
- Outdoor & Kiosk Systems:
- ATMs & Self-Service Terminals: High brightness ensures readability even in brightly lit indoor or semi-outdoor environments.
- Public Information Displays: Touch panels for ticketing or information
