TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial

SKU: TM047NBHG03
Model P/N: TM047NBHG03
Diagonal Size: 4.7"
Panel Type: a-Si TFT-LCD, LCM
Resolution: 1280 × 720
Pixel Format: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$33.00 $32.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
1/1
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
  • Description
TM047NBHG03 Tianma 4.7 inch LCD Panel For Industrial
Parameter Value
Manufacturer Tianma
Model Number TM047NBHG03
Panel Type a-Si TFT-LCD, Transmissive, Normally Black
Diagonal Size 4.7 inch
Resolution 1280 × 720 (HD, 16:9)
Pixel Format RGB Vertical Stripe
Active Area 104.26 × 58.64 mm
Outline Dimensions 110.4 × 66.3 × 2.6 mm
Pixel Pitch 0.0815 × 0.0815 mm
Brightness 600 cd/m² (Typ.)
Contrast Ratio 1500:1 (Typ.)
Display Colors 262K colors (6-bit)
Color Gamut 60% NTSC (Typ.)
Response Time 30 ms (Typ.)
Viewing Angle 70/70/50/70° (L/R/U/D, CR≥10)
Surface Anti-glare
Backlight WLED, Edge type
Refresh Rate 60 Hz
Signal Interface MIPI DSI (2 lanes)
Supply Voltage 3.3 V (Typ.)
Operating Temp -20 ~ +70 °C
Storage Temp -30 ~ +80 °C

Applications

  • Industrial handheld terminals & data collectors
  • Vehicle-mounted displays & car navigation systems
  • Portable medical diagnostic & monitoring devices
  • Smart home control panels & human-machine interfaces
  • Industrial control & test equipment
  • Wearable & mobile embedded displays
  • Outdoor & high-brightness handheld devices
  • POS machines & financial terminals
