TM089CFSP01 | Tianma 8.9-inch 4K Monochrome SLA 3D Printing LCD Panel

TM089CFSP01 is an 8.9-inch monochrome a-Si SFT TFT-LCD panel manufactured by Tianma, with ultra-high 3840×2400 WQUXGA resolution and 508 PPI pixel density. It features 800:1 high contrast, full symmetrical 85° wide viewing angle, 4-lane MIPI interface, no built-in backlight, thin 1.24mm glass thickness, and wide industrial temperature range. It is specially designed for resin SLA/DLP 3D printers, and also applicable to precision optical exposure equipment and industrial micro-display systems.
Parameter Item Specification Details
Part Number TM089CFSP01 (TM089CFSP01-00)
Manufacturer Tianma Microelectronics (天马微电子)
Display Size 8.9 inch, landscape, 16:10 aspect ratio
Native Resolution 3840(H) × 2400(V) pixels (WQUXGA)
Display Technology a-Si TFT-LCD, SFT mode, transmissive monochrome
Pixel Pitch 0.05 × 0.05 mm
Pixel Density 508 PPI
Active Area (AA) 192 mm (W) × 120 mm (H)
Overall Outline Dimension 202 × 133 × 1.24 mm
Typical Brightness 0 cd/m² (No internal backlight, UV light source matched externally)
Typical Contrast Ratio 800:1 (Transmissive mode)
Viewing Angle (L/R/U/D, CR≥10) 85° / 85° / 85° / 85°, full symmetrical wide angle
Response Time (Tr+Td) 25 ms (Typical)
Gray Scale 8-bit grayscale, 256 gray levels
Backlight System Without built-in backlight, matched with external UV LED light source for 3D curing
Signal Interface MIPI DSI (4 data lanes), 50-pin FPC connector
Logic Supply Voltage VDDI=1.8 VDC, VDD=3.3 VDC (Typ.)
Refresh Rate 60 Hz
Operating Temperature -10°C ~ +70°C
Storage Temperature -20°C ~ +80°C
Touch Function Without touch panel
Surface Treatment Clear glossy surface, no anti-glare coating
Net Weight Approx. 120 g
Compliance Standard RoHS compliant
Production Status Discontinued legacy model, mainly used as replacement screen for old SLA 3D printers
