| Manufacturer |
TIANMA |
| Model Number |
TM156VDSG16 |
| Panel Type |
a-Si TFT-LCD, SFT (Super Fine TFT), Normally Black, Transmissive LCM |
| Diagonal Size |
15.6 inches |
| Resolution |
1920 (RGB) × 1080 (FHD), Aspect Ratio 16:9 |
| Pixel Density |
141 PPI |
| Pixel Configuration |
RGB Vertical Stripe |
| Pixel Pitch |
0.17925 × 0.17925 mm |
| Active Area |
344.16 (W) × 193.59 (H) mm |
| Outline Dimensions |
363.8(W)×215.9(H)×6.8(D) mm |
| Weight |
610 g (Typical) |
| Surface Treatment |
Anti-glare (Matte), Hard Coating (3H min.) |
| Brightness |
400 cd/m² (Typical) |
| Contrast Ratio |
1000:1 (Typical, Transmission) |
| Viewing Angle |
88° (L/R/U/D) (Typical, CR≥10) |
| Response Time |
25 ms (Typical, Tr+Td) |
| Refresh Rate |
60 Hz |
| Color Depth |
8-bit, 16.7M Colors, 72% NTSC (Typical) |
| Backlight |
WLED, Edge-type, Lifetime: 50,000+ hours, Built-in LED Driver |
| Backlight Voltage |
12.0V (Typical) |
| Signal Interface |
eDP 1.4, 40 pins, 2 Lanes, 8-bit |
| Connector |
I-PEX 20455-040E-11 (0.5mm pitch) |
| Supply Voltage |
3.3V (Typical) |
| Power Consumption |
13.9W (Typical, Full On) |
| Operating Temperature |
-20°C ~ 70°C |
| Storage Temperature |
-20°C ~ 70°C |
| Vibration Resistance |
1.2G (11.76 m/s²) |
| Touch Panel |
No Touch (Without TSP) |
| Production Status |
Mass Production |
|
|
|
