New Touch Screen TP-3373S1

1. Physical Specifications

• Screen Size: Typically 5.7 inches (diagonal) based on standard "TP-33xx" sizing conventions.

• Outline Dimensions: Often approximately 160mm × 120mm (varies by manufacturer).

• Active Area (AA): Approximately 115mm × 86mm.

• Structure: Glass + Film (ITO) construction.

• Connection: Usually a 4-wire (or 5-wire) FPC (Flexible Printed Circuit) tail with a specific pin pitch (commonly 1.0mm or 1.25mm).

2. Electrical & Touch Characteristics

• Technology: Analog Resistive.

• Activation Force: 50g – 100g (typical).

• Linearity: ≤ 1.5%.

• Insulation Resistance: ≥ 20MΩ (DC 25V).

• Operating Voltage: ≤ 5V DC.

3. Environmental & Durability

• Operating Temperature: -10°C to +60°C.

• Storage Temperature: -20°C to +70°C.

• Operating Humidity: 20% – 85% RH (non-condensing).

• Surface Hardness: ≥ 3H.

• Touch Life: ≥ 1,000,000 touches (single point).
