Hitachi TX09D34VM3CPA 3.5" QVGA TFT LCD 240×320 Industrial Display

Name: Hitachi TX09D34VM3CPA 3.5" QVGA TFT LCD 240×320 Industrial Display
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: TX09D34VM3CPA
Price: 110 USD
Availability: InStock

SKU: TX09D34VM3CPA

Model: TX09D34VM3CPA
Brand: Hitachi
Size: 3.5 inch (Diagonal)
Display Type: a-Si TFT-LCD Module (LCM)
Resolution: 240(RGB)×320 (QVGA), 113 PPI

0.0 (0 Reviews)

0 Sold

~~$130.00~~ $110.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

Hitachi TX09D34VM3CPA 3.5" QVGA TFT LCD 240×320 Industrial Display

Item	Specification
Model	TX09D34VM3CPA
Brand	Hitachi
Size	3.5 inch (Diagonal)
Display Type	a-Si TFT-LCD Module (LCM)
Resolution	240(RGB)×320 (QVGA), 113 PPI
Brightness	340 cd/m² (Typ.)
Contrast Ratio	300:1 (Typ.)
Viewing Angle	L/R/U/D: 50°/80°/80°/80°
Display Colors	262K Colors, 46% NTSC
Backlight	WLED, Lifespan: 40,000 Hours
Interface	CMOS 6-bit, 1 Channel, 50-pin FPC
Operating Temperature	-30℃ ~ +80℃
Storage Temperature	-30℃ ~ +80℃
Compliance	RoHS
Outline Dimension	64(W)×86(H)×5.5(D) mm
Weight	Approx. 44g
Surface Treatment	Antiglare, Hard coating (3H)

Applications

Industrial HMI & PLC Panels: Automation control rooms, factory machine operation terminals (wide temperature & vibration resistance).
Handheld Industrial Devices: Industrial PDAs, data collectors, barcode scanners, portable measuring instruments.
Medical Equipment: Portable patient monitors, analytical devices, medical control panels (stable & long lifespan).
Vehicle & Marine Displays: Construction machinery, forklifts, in-vehicle terminals, ship instrument panels.
Outdoor Kiosks & Terminals: ATM, self-service query machines, access control displays (sunlight readable).
Specialty Instruments: Surveying, environmental monitoring, power meters, and industrial test equipment.
