| Parameter | Specification |
|---|---|
| Brand / Model | HITACHI / TX09D40VM3CBA |
| Diagonal Size | 3.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 240(RGB)×320, QVGA |
| Pixel Format | RGB Vertical Stripe |
| Active Area (W×H) | 53.64 × 71.52 mm |
| Bezel Opening (W×H) | 57.64 × 75.52 mm |
| Outline Dim. (W×H×D) | 86.0 × 64.0 × 4.5 mm |
| Luminance (Typ.) | 430 cd/m² |
| Contrast Ratio (Typ.) | 300:1 |
| View Direction | 9 o‘clock |
| Viewing Angle (L/R/U/D, CR≥5) | 80/50/80/80 |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color / NTSC | 262K / 46% |
| Light Source | WLED [3S2P] |
| Backlight Driver | Without (W/O Driver) |
| Weight (Typ.) | 36.0g |
| Designed For | Handheld & PDA |
| Touch Panel | Without |
| Interface Type | Parallel RGB (1 ch, 6-bit) |
| Connector | 50 pins FPC |
| Power Supply (Typ.) | VCC: 3.0V, VDH: 8.45V, VGH: 16.5V, VGL: -8.05V |
| Operating Temperature | -30 ~ 80 °C |
| Storage Temperature | -30 ~ 80 °C |
The TX09D40VM3CBA is an ideal choice for:
Industrial control panels and HMIs
Portable handheld devices
Medical equipment
Test and measurement instruments
Embedded systems requiring a compact color display
