| Feature | Specification |
|---|---|
| Screen Size | 4.3 inches (diagonal) |
| Resolution | 480 x 272 pixels (WQVGA) |
| Display Type | TFT (Thin-Film Transistor) LCD |
| Active Area | 95.04 mm (W) × 53.856 mm (H) |
| Brightness | Typically 300 ~ 450 cd/m² |
| Viewing Angle | Wide Viewing Angle (IPS/FFS technology likely) |
| Interface | Parallel RGB (e.g., 24-bit, 18-bit, or 16-bit) |
| Touch Panel | Not Integrated (Display-only module) |
| Backlight | White LED, edge-lit |
| Backlight Lifetime | Typically 20,000 ~ 50,000 hours |
| Power Supply (Logic) | +3.3V (Typical) |
| Power Supply (Backlight) | +3.3V to +5.0V (Depends on LED configuration) |
| Operating Temperature | Standard: -20°C ~ +70°C |
☛Delivery Details:
We will arrange the shipment within 1-3 working days asap after got your payment. And the tracking number and commercial inovice will be given to the customers asap. (only the standard speedpak or expedited shipping service). Expedited Shipping by DHL/FEDEX/4PX express Courier etc. But sometimes it is highly depended on buyer's payment, the courier company and local customs/duties.
☛About us:
We have specialized in LCD-Business for 20 years(NEC, SHARP, HITACHI, AUO, SAMSUNG, KOE, TIANMA LG Display, Samsung, Innolux, SHARP, MISTBISH,etc)
We are willing to provide the good service,professional technology and excellent products to you.
If you have any general questions and please contact us via julie@atssservice.com ,we will give you a exact reply within 24hours.
