The TX13D06VM5BAA is engineered for demanding environments where consistent image quality and reliability are critical. Its UWVA technology provides stable color uniformity essential for professional interfaces .
Industrial Human-Machine Interfaces (HMI): Widely used in industrial PCs and control panels for factory automation, where its high brightness (1000 cd/m²) ensures readability under various lighting conditions .
Medical Equipment: Suitable for patient monitors and diagnostic devices due to its wide viewing angles (80° all directions), color homogeneity, and long-term product availability .
In-Vehicle Displays: Ideal for automotive or transportation applications, supported by its extremely wide operating temperature range (-30°C to +80°C) and high brightness for daylight visibility .
Outdoor Terminals: Perfect for kiosks or ticketing machines exposed to sunlight, as the anti-glare surface treatment combined with the high brightness (1000 cd/m²) minimizes reflections and maintains clarity .
This model is valued for its cost-effective "IPS-like" optical performance, rugged design, and suitability for harsh environments requiring stable color reproduction from a TN-based TFT .
| Parameter | Specification |
|---|---|
| Manufacturer | KOE (Kaohsiung Opto-Electronics) / Hitachi |
| Screen Size | 5.0 inches |
| Resolution (Format) | 800 x 480 pixels (WVGA / 16:9 aspect ratio) |
| Display Technology | UWVA (Ultra Wide Viewing Angle) - "IPS-like" performance based on TN |
| Active Area (W x H) | 108.0 x 64.8 mm |
| Outline Dimensions (W x H x D) | 120.0 x 80.7 x 8.5 mm |
| Brightness | 1000 cd/m² (Typical) |
| Contrast Ratio | 400:1 (Typical) |
| Viewing Angle | 80° in all directions (up/down, left/right) |
| Interface | 40-pin CMOS (1 ch, 6-bit) |
| Backlight | White LED, 50,000 hours lifetime |
| Operating Temperature | -30°C to +80°C |
| Storage Temperature | -30°C to +80°C |
| LCD Type | Normally White, Transmissive TN |
| Color Depth | 262,144 colors (6-bit) |
| Surface Treatment | Matte (Anti-glare) |
FAQ
Q: How long will I receive my goods ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX
Q:Can you give me a discount if I need a large quantity of ?
A:Of course!If you make a large order, we will give you a discount.
Q:Can I pay my order via credit card ?
A:Yes!you can use your credit card through your Paypal account.
A: We use anti-static packaging and shock-resistant packaging.Anti-static packaging: Ensure that the packaging materials used comply with ESD standards, including anti-static bags and foam.Shock-resistant packaging: Use custom foam and sturdy outer boxes to ensure that they can pass through regular transportation tests (such as dropping and vibration).So the goods arrive at your hands in perfect condition.
Q: Do you conduct tests before shipment?
A: Yes, we strictly follow 100% pre-shipment testing procedures.Our testing process is standardized to ensure that every LCD panel sent to you is in compliance with specifications and is fully functional.
