Hitachi / KOE TX16D11VM2CPC 6.2 inch 640×240 LCD Display Screen For Industrial
| Item |
Specification |
Unit |
| Model |
TX16D11VM2CPC |
– |
| Brand |
Hitachi / KOE (Japan) |
– |
| Display Type |
a-Si TFT-LCD, LCM (TN, Normally White, Transmissive) |
– |
| Diagonal Size |
6.2 |
inch |
| Resolution |
640(RGB) × 240 (HVGA), 109 PPI |
– |
| Active Area (W×H) |
148.8 × 53.76 |
mm |
| Outline Dimension |
173 × 70 × 10.5 (max) |
mm |
| Brightness |
280 (Typ.) |
cd/m² |
| Contrast Ratio |
200:1 (Typ.) |
– |
| Viewing Angle (CR≥10) |
70/70/60/70 (L/R/U/D) |
° |
| Display Colors |
262K (18-bit RGB) |
– |
| Backlight |
1×CCFL, 50,000 hrs (25°C, no driver) |
– |
| Interface |
TTL (Parallel), 20-pin connector |
– |
| Supply Voltage |
3.3 (Typ.) |
V |
| Operating Temperature |
-20 ~ +70 |
°C |
| Storage Temperature |
-30 ~ +80 |
°C |
| Vibration Resistance |
2.0G (industrial grade) |
– |
| Surface Treatment |
AG (Anti-Glare) |
– |
| Weight |
Approx. 140 |
g |
| Compliance |
RoHS |
– |
Typical Applications（English）
- Industrial HMI & Control Panels: Small CNC, PLC, factory automation, test & measurement equipment (compact size + wide temp)
- Medical & Lab Devices: Portable diagnostic tools, patient monitors, laboratory instruments (reliable, low power)
- Vehicle & Marine Displays: Forklifts, construction machinery, ship instruments (rugged, vibration-resistant)
- Point of Sale (POS) & Kiosks: Cash registers, ticket machines, self-service terminals (AG coating for bright environments)
- Legacy System Replacement: Old industrial displays, embedded systems (drop-in compatible with TX16D series)
