KOE/Hitachi TX18D206VM0BYA 7" WVGA TFT LCD 800×480 Industrial Display

Name: KOE/Hitachi TX18D206VM0BYA 7" WVGA TFT LCD 800×480 Industrial Display
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: TX18D206VM0BYA
Price: 235 USD
Availability: InStock

SKU: TX18D206VM0BYA

Model TX18D206VM0BYA
Brand KOE (Hitachi)
Size 7.0 inch (Diagonal)
Display Type a-Si TFT-LCD, IPS
Resolution 800(RGB)×480, WVGA, 133 PPI

0.0 (0 Reviews)

0 Sold

~~$237.00~~ $235.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

KOE/Hitachi TX18D206VM0BYA 7" WVGA TFT LCD 800×480 Industrial Display

Item	Specification
Model	TX18D206VM0BYA
Brand	KOE (Hitachi)
Size	7.0 inch (Diagonal)
Display Type	a-Si TFT-LCD, IPS (In-Plane Switching)
Resolution	800(RGB)×480, WVGA, 133 PPI
Brightness	700 cd/m² (Typ.)
Contrast Ratio	1000:1 (Typ.)
Viewing Angle	L/R/U/D: 85°/85°/85°/85° (CR≥10)
Display Colors	262K Colors (6-bit RGB), 72% NTSC
Backlight	WLED, Lifespan: 70,000 Hours, with Driver
Interface	LVDS (1 ch, 6-bit), 20 pins Connector
Operating Temperature	-30℃ ~ +80℃
Storage Temperature	-40℃ ~ +90℃
Vibration Resistance	5.0G
Compliance	RoHS
Active Area	152.4(W) × 91.44(H) mm
Outline Dimension	170(W) × 113.3(H) × 22(D) mm
Weight	Approx. 295g

Applications

Industrial HMI & Control Panels: Factory automation, PLC terminals, CNC machinery (wide temp & high vibration resistance).
Vehicle & Marine Displays: Forklifts, construction machinery, in-vehicle infotainment, ship instrument panels (IPS full viewing angle).
Medical Equipment: Portable diagnostic devices, patient monitors, medical control terminals (stable performance & long lifespan).
Outdoor Kiosks & Terminals: Self-service machines, access control, outdoor monitoring (700cd/m² bright & anti-glare).
Smart Industrial Devices: Industrial PDAs, data collectors, barcode scanners, portable test equipment.
Specialty Instruments: Surveying, environmental monitoring, power meters, and industrial test equipment.
