KOE TX18D211VM0BYA 7 Inch 800×480 TFT LCD Panel Industrial Display Screen
| Item |
Detailed Parameter |
| Manufacturer |
KOE (JDI Hitachi Display) |
| Model Number |
TX18D211VM0BYA |
| Diagonal Screen Size |
7.0 Inch |
| Panel Type |
LTPS a-Si TFT-LCD, Transmissive LCM Module |
| Native Resolution |
800(RGB) × 480 (WVGA), 16:9 Aspect Ratio, 133 PPI |
| Pixel Format |
RGB Vertical Stripe |
| Display Mode |
IPS, Normally Black, Transmissive |
| Typical Brightness |
1000 cd/m² (Sunlight Readable) |
| Typical Contrast Ratio |
1000:1 (TM Mode) |
| Viewing Angle (U/D/L/R) |
85° / 85° / 85° / 85° (CR≥10) |
| View Direction |
Symmetry |
| Backlight |
WLED, 50,000 Hours Lifespan, With Integrated LED Driver IC |
| Signal Interface |
LVDS (1 Channel, 6-bit), 20 Pins Connector |
| Refresh Frequency |
60Hz |
| Touch Function |
Without Touch Screen (PCAP touch bonding available) |
| Typical Supply Voltage |
3.3V |
| Operating Temperature |
-20 ℃ ~ +70 ℃ |
| Storage Temperature |
-30 ℃ ~ +80 ℃ |
Application Scenarios
1. Construction & Agricultural Machinery Cabin Displays
- Excavator, loader, forklift cabin HMI control panels
- Tractor, harvester agricultural equipment dashboard screens
- Engineering vehicle real-time parameter monitoring terminals
- Off-road heavy machinery outdoor operation display modules
2. Outdoor & Semi-Outdoor Self-Service Kiosks
- Roadside parking payment self-service terminals
- Outdoor vending machine interactive display screens
- Gas station fuel dispenser operation interfaces
- Outdoor public information inquiry kiosks
3. Portable Industrial Field Testing Equipment
- Handheld environmental monitoring analyzers
- Portable industrial measuring & calibration instruments
- Field survey and mapping data display terminals
- Outdoor portable medical diagnostic devices
4. Special Vehicle & Marine Equipment
- RV and bus central control small display screens
- Marine ship cabin auxiliary parameter monitoring panels
- Special engineering vehicle touch base operation terminals
