TX20D18VM2BPA 8.0inch LCD Panel with 4-wire Resistive Touch

Name: TX20D18VM2BPA 8.0inch LCD Panel with 4-wire Resistive Touch
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: TX20D18VM2BPA
Price: 75 USD
Availability: InStock

SKU: TX20D18VM2BPA

Model P/N:TX20D18VM2BPA
Diagonal Size: 8.0"
Panel Type: a-Si TFT-LCD, LCM
Resolution:800(RGB)×480, WVGA 116PPI
Pixel Format: RGB Vertical Stripe

0.0 (0 Reviews)

0 Sold

~~$77.00~~ $75.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

The TX20D18VM2BPA is a fully integrated 8.0-inch TFT LCD display module featuring a built-in 4-wire Resistive Touch Panel. It is designed as a complete input/output solution for interactive applications requiring a cost-effective and reliable touch interface

Parameter	Specification / Description
Display Model	TX20D18VM2BPA
Display Type	a-Si TFT LCD
Screen Size	8.0 inches
Active Area	174(W)×104.4(H) mm
Resolution	800 (RGB) x 480 pixels
Pixel Format	RGB Stripe
Brightness (Typical)	280 cd/m² (Typ.)
Contrast Ratio	200:1 (Typ.) (TM)
Viewing Angle	50/50/50/50 (Typ.)(CR≥10)
Surface Treatment	Anti-Glare Hard Coating (on LCD surface)
Touch Panel Type	4-Wire Analog Resistive
Backlight	CCFL [1 pcs]
Display Interface	Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Typical Applications	Industrial HMI, POS systems, Medical devices, Instrumentation, Kiosks, Embedded systems.

Applications:

Industrial HMIs (Human-Machine Interfaces)
Medical equipment and patient monitors
Point-of-Sale (POS) terminals
Navigation and marine systems
Test and measurement instruments
Factory automation controls

☛Delivery Details:

We will arrange the shipment within 1-3 working days asap after got your payment. And the tracking number and commercial inovice will be given to the customers asap. (only the standard speedpak or expedited shipping service). Expedited Shipping by DHL/FEDEX/4PX express Courier etc. But sometimes it is highly depended on buyer's payment, the courier company and local customs/duties.

☛About us:

We have specialized in LCD-Business for 20 years(NEC, SHARP, HITACHI, AUO, SAMSUNG, KOE, TIANMA LG Display, Samsung, Innolux, SHARP, MISTBISH,etc)

We are willing to provide the good service,professional technology and excellent products to you.

If you have any general questions and please contact us via julie@atssservice.com ,we will give you a exact reply within 24hours.
