Display Size: 8.0 inches
Resolution: 800 (RGB) × 480 pixels (WVGA)
Panel Type ：a-Si TFT-LCD, LCM
Pixel Format：RGB Vertical Stripe
| Parameter | Specification | Notes |
|---|---|---|
| Model | TX20D28VM2BAB | 8.0-inch TFT-LCD module |
| Display Size | 8.0 inch | Diagonal measurement |
| Resolution | 800 × RGB × 480 (WVGA) | 800×480 pixels |
| Active Area | 174(W)×104.4(H) mm | Visible display area |
| Display Type | a-Si TFT, Transmissive | Normally white |
| Brightness | 550 cd/m² (Typ.) | LED backlight |
| Contrast Ratio | ~800:1 (Typical) | High contrast display |
| Viewing Angle | Wide (IPS/FFS type) | ~80°/80°/80°/80° (L/R/U/D) |
| Interface | RGB Vertical Stripe | RGB Vertical Stripe |
| Backlight | White LED | Long lifetime (~50K hours) |
| Operating Temp | -20°C to +70°C | Industrial grade |
| Touch Option | Without | Usually as separate variant |
| Applications | Industrial HMI, Automotive, POS, Medical | Rugged design |
The TX20D28VM2BAB is specifically designed for high-brightness and industrial applications, including :
Industrial Human-Machine Interfaces (HMI) – Factory automation and control panels
Marine Navigation Systems – Bridge displays, chartplotters
Home Automation (Domotics) – Smart home control panels
Media Entertainment Systems – In-vehicle entertainment, kiosks
Outdoor Information Displays – Kiosks, digital signage
Medical Equipment – Diagnostic and monitoring devices
Test & Measurement Instruments – Benchtop and portable equipment
