UMSH-8377MD-8T 5.7 INCH 640×480 LCD Display Screen For Industrial

Name: UMSH-8377MD-8T 5.7 INCH 640×480 LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: UMSH-8377MD-8T
Price: 82 USD
Availability: InStock

SKU: UMSH-8377MD-8T

Model: UMSH-8377MD-8T
Screen Size: 5.7 inches
Display Type: a-Si TFT-LCD Module
Resolution: 640 × 480 pixels (VGA)

0.0 (0 Reviews)

0 Sold

~~$85.00~~ $82.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

UMSH-8377MD-8T 5.7 INCH 640×480 LCD Display Screen For Industrial

Item	Specification
Model	UMSH-8377MD-8T
Screen Size	5.7 inches
Display Type	a-Si TFT-LCD Module
Resolution	640 × 480 pixels (VGA)
Brightness	350 cd/m² (Typ.)
Contrast Ratio	600:1 (Typ.)
Viewing Angle	75°/75°/60°/75° (L/R/U/D)
Interface	TTL (Parallel RGB)
Backlight	WLED, 50,000 hrs lifespan
Touch Panel	4-wire resistive touch
Active Area	115.2(W)×86.4(H) mm
Outline Dimensions	127(W)×98.43(H)×10.06(D) mm
Weight	120 g (Typ.)
Operating Temperature	-20 °C ~ +70 °C
Storage Temperature	-30 °C ~ +80 °C
RoHS Compliance	Yes

Specific Application

Industrial HMI & Automation: For PLC panels, industrial PCs, and factory monitoring systems.
Medical Devices: Used in diagnostic equipment, patient monitors, and portable medical instruments.
Smart Handheld & Instrumentation: Applied in industrial handheld terminals, test equipment, and gauges.
Outdoor & Rugged Systems: Suitable for outdoor kiosks, transportation terminals, and harsh-environment interfaces.
Retail & POS: For point-of-sale terminals and self-service machines with stable performance.
