UMSH-8839MD-T 5.7 Inch LCD Display Screen For Industrial

Name: UMSH-8839MD-T 5.7 Inch LCD Display Screen For Industrial
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: UMSH-8839MD-T
Price: 100 USD
Availability: InStock

SKU: UMSH-8839MD-T

Model: UMSH‑8839MD‑T
Panel Size: 5.7 inches (diagonal)
Resolution: 640 × 480 (VGA)
Display Type: a‑Si TFT‑LCD, TN

0.0 (0 Reviews)

0 Sold

~~$120.00~~ $100.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

UMSH-8839MD-T 5.7 Inch LCD Display Screen For Industrial

Parameter	Details
Model	UMSH‑8839MD‑T
Brand	URT (UNITED RADIANT TECHNOLOGY)
Panel Size	5.7 inches (diagonal)
Resolution	640 × 480 (VGA)
Display Type	a‑Si TFT‑LCD, TN, Normally White, Transmissive
Active Area	115.2 × 86.4 mm
Outline Dimension	127 × 127 × 10.06 mm (max)
Brightness	350 cd/m² (Typ.)
Contrast Ratio	600:1 (Typ.)
Viewing Angle	75°/75°/60°/75° (L/R/U/D)
Response Time	15/35 ms (Tr/Td, Typ.)
Backlight	WLED, 50,000 hrs lifespan
Interface	TTL, 40‑pin, 6‑bit RGB
Touch Screen	Integrated 4‑wire resistive touch (single‑touch)
Operating Voltage	DC 5V (logic), 12V (backlight)
Operating Temperature	−20°C ~ +70°C
Storage Temperature	−30°C ~ +80°C
Weight	~120 g
RoHS Compliance	Yes

Applications

Industrial Control: HMI panels, CNC machines, injection molding machines, industrial PCs, PLC terminals
Medical Equipment: Patient monitors, diagnostic devices, medical imaging displays, portable medical instruments
Automotive & Transportation: Industrial vehicle dashboards, marine displays, in‑vehicle infotainment
Smart Terminals: POS systems, ATM banking displays, vending machines, industrial touch monitors
Others: Projector panels, intelligent home control panels, outdoor industrial displays
