| Construction | Metal frame, edge-lit backlight system |
| Primary Use | Embedded industrial, medical, instrumentation, portable devices |
| Parameter | Specification |
|---|---|
| Display Size | 6.5 inches diagonal |
| Aspect Ratio | 4:3 |
| Resolution | 640 × 480 pixels (VGA) |
| Active Area | 132.48 mm × 99.36 mm |
| Pixel Pitch | 0.207 mm × 0.207 mm |
| Brightness | 300 cd/m² (typical) |
| Contrast Ratio | 300:1 (typical) |
| Viewing Angles | 70° (H) / 50° (U) / 60° (D) |
| Color Depth | 262,144 colors (6-bit + FRC) |
| Response Time | 35 ms (Tr+Tf) |
| Backlight Type | CCFL (Cold Cathode Fluorescent Lamp) |
| Backlight Lifetime | 20,000-30,000 hours |
| Power Consumption | Panel: ~1.5 W; Total with backlight: 3.5-5.0 W |
| Outline Dimensions | 149.0 mm × 118.0 mm × 7.5 mm (max) |
| Weight | Approx. 150 g |
| Operating Temperature | -10°C to +60°C |
| Special Features | Standard industrial grade |
| Parameter | Specification |
|---|---|
| Display Size | 6.5 inches diagonal |
| Aspect Ratio | 4:3 |
| Resolution | 640 × 480 pixels (VGA) |
| Active Area | 132.48 mm × 99.36 mm |
| Pixel Pitch | 0.207 mm × 0.207 mm |
| Brightness | 400 cd/m² (typical) – Higher than EM10 |
| Contrast Ratio | 350:1 (typical) |
| Viewing Angles | 70° (H) / 50° (U) / 60° (D) – Similar to EM10 |
| Color Depth | 262,144 colors (6-bit + FRC) |
| Response Time | 35 ms (Tr+Tf) |
| Backlight Type | CCFL – Possibly optimized for higher brightness |
| Backlight Lifetime | 20,000-30,000 hours (may be reduced due to higher brightness) |
| Power Consumption | Panel: ~1.5 W; Total with backlight: 4.0-6.0 W (higher due to brighter backlight) |
| Outline Dimensions | 149.0 mm × 118.0 mm × 7.5 mm (max) – Identical to EM10 |
| Weight | Approx. 150 g |
| Operating Temperature | -10°C to +60°C |
| Special Features | High-brightness version of EM10 for better ambient light readability |
| Parameter | Specification |
|---|---|
| Display Size | 6.5 inches diagonal |
| Aspect Ratio | 4:3 |
| Resolution | 640 × 480 pixels (VGA) |
| Active Area | 132.48 mm × 99.36 mm |
| Pixel Pitch | 0.207 mm × 0.207 mm |
| Brightness | 300 cd/m² (typical) – Same as EM10 |
| Contrast Ratio | 300:1 (typical) |
| Viewing Angles | 70° (H) / 50° (U) / 60° (D) |
| Color Depth | 262,144 colors (6-bit + FRC) |
| Response Time | 35 ms (Tr+Tf) |
| Backlight Type | CCFL |
| Backlight Lifetime | 20,000-30,000 hours |
| Power Consumption | Panel: ~1.5 W; Total with backlight: 3.5-5.0 W |
| Outline Dimensions | 149.0 mm × 118.0 mm × 7.5 mm (max) |
| Weight | Approx. 150 g |
| Operating Temperature | -20°C to +70°C – Wider range than EM10/EC10 |
| Special Features | Extended temperature version for harsh environments |
| Feature | V606EM10 | V606EC10 | V606EM20 |
|---|---|---|---|
| Brightness | 300 cd/m² | 400 cd/m² (High Brightness) | 300 cd/m² |
| Contrast Ratio | 300:1 | 350:1 | 300:1 |
| Operating Temperature | -10°C to +60°C | -10°C to +60°C | -20°C to +70°C (Wide Temp) |
| Power Consumption | 3.5-5.0 W | 4.0-6.0 W (Higher) | 3.5-5.0 W |
| Primary Differentiation | Standard industrial | High brightness for bright environments | Wide temperature for harsh conditions |
| Typical Application | General industrial HMI | Outdoor/kiosk/sunlight readable | Automotive/outdoor/cold storage |
| Backlight Stress | Standard | Higher drive (shorter lifetime potential) | Standard with temp compensation |
| Cost Relative | Baseline | Higher (due to brighter backlight) | Higher (due to wide temp components) |
| Parameter | All Models |
|---|---|
| Logic Supply Voltage (Vdd) | 3.3 V DC ±0.3 V |
| Signal Interface | LVDS (2-channel, 18/24-bit) |
| Connector | 20-pin or 30-pin FPC connector |
| Pixel Clock Frequency | 25.175 MHz (for 640x480 @ 60Hz) |
| Sync Signals | Separate Hsync, Vsync |
| Backlight Inverter Input | 12 V DC typical (external inverter required) |
| Backlight Dimming | Analog (0-5V) or PWM control supported |
