VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial

SKU: VGG804806-6UFLWE
Model: VGG804806-6UFLWE
Display Size: 7.0"
Panel Type: a-Si TFT-LCD, Industrial Grade
Resolution: 800 × 480 (WVGA, 15:9 aspect ratio)
Dot Layout: RGB Vertical Stripe
0.0 (0 Reviews)
0 Sold
$146.00 $143.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
-
+
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
1/1
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
  • Description
VGG804806-6UFLWE 7 Inch 800 × 480 LCD Dispaly Panel For Industrial
Parameter Details
Model VGG804806-6UFLWE
Display Size 7.0"
Panel Type a-Si TFT-LCD, Industrial Grade
Resolution 800 × 480 (WVGA, 15:9 aspect ratio)
Dot Layout RGB Vertical Stripe
Active Area 152.4 × 91.44 mm
Outline Size 166.6 × 109.4 × 10.0 mm (typical)
Contrast Ratio 500:1 (Typ.)
Viewing Angle 70°/70°/60°/60° (L/R/U/D, CR≥10)
Display Mode TN, Normally White, Transmissive
Backlight WLED, long lifetime, with integrated LED driver
Response Time 25 ms (Typ.)
Display Colors 16.7M colors
Input Voltage 3.3V / 5V (Typ., logic/panel)
Operating Temperature -20 °C ~ +70 °C
Storage Temperature -30 °C ~ +80 °C
