7 Inch LG Display LB070WV1-TD17 TFT LCD Screen 800x480 for HMI

Name: 7 Inch LG Display LB070WV1-TD17 TFT LCD Screen 800x480 for HMI
Brand: TSS SERVICE CENTER CO., LIMITED
SKU: LB070WV1-TD17
Price: 168 USD
Availability: InStock

SKU: LB070WV1-TD17

Model: LB070WV1-TD17
Brand: LG Display
Size: 7.0 inch (Diagonal), 15:9 Aspect Ratio
Display Type: a-Si TFT-LCD, TN, Normally White, Transmissive
Resolution: 800(RGB)×480, WVGA, 133PPI

0.0 (0 Reviews)

0 Sold

~~$175.00~~ $168.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

1/1

Description

7 Inch LG Display LB070WV1-TD17 TFT LCD Screen 800x480 for HMI

Item	Specification
Model	LB070WV1-TD17
Brand	LG Display
Size	7.0 inch (Diagonal), 15:9 Aspect Ratio
Display Type	a-Si TFT-LCD, TN, Normally White, Transmissive
Resolution	800(RGB)×480, WVGA, 133PPI
Brightness	400 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.)
Viewing Angle	L/R/U/D: 60°/60°/40°/50° (CR≥10)
Display Colors	262K (6-bit RGB)
Backlight	2×CCFL, Lifespan: 30,000 Hours, With Inverter
Interface	Parallel RGB (1 ch, 6-bit), 40 Pin FPC Connector
Supply Voltage	3.3V (Typ.)
Operating Temperature	-10℃ ~ +60℃
Storage Temperature	-20℃ ~ +70℃
Active Area	152.4(W) × 91.44(H) mm
Outline Dimension	165(W) × 105(H) × 10.5(D) mm
Weight	Approx. 300g
Refresh Rate	60Hz
Touch Panel	Without Touch
Compliance	RoHS
